7.4 Sensor Module Cabinet-Mounted SMC30
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
219
7.4.9 Technical Specifications
Table 7- 19 Technical data
6SL3055-0AA00-5CAx Unit Value
Electronics power supply
Voltage
Current (without encoder system)
Current (with encoder system)
Power loss
V
DC
A
DC
A
DC
W
24 DC (20.4 – 28.8)
≤ 0.20
≤ 0.55
≤ 10
Encoder system power supply
Voltage
Current
V
encoder
A
encoder
5 VDC (with or without Remote Sense)
1)
or V
DC
- 1 V
0.35
Encoder frequency that can be evaluated
(f
encoder
)
kHz ≤ 300
SSI baud rate kHz 100 - 250
PE/ground connection On housing with M4/1.8 Nm screw
Weight 0.45
Degree of protection IP20 or IPXXB
1) A controller compares the encoder system supply voltage - sensed via the Remote Sense cables - with the reference
supply voltage of the encoder system, and adjusts the supply voltage for the encoder system at the output of the drive
module until the required supply voltage is obtained directly at the encoder system (only for 5 V encoder system power
supply). Remote Sense only to X520.
Table 7- 20 Specification of encoder systems that can be connected
Parameter Designation Threshold Min. Max. Unit
High signal level
(TTL bipolar at X520 or X521/X531)
1)
U
Hdiff
2 5 V
Low signal level
(TTL bipolar at X520 or X521/X531)
1)
U
Ldiff
-5 -2 V
High 17 V
CC
V Signal level high
(HTL unipolar)
U
H
3)
Low 10 V
CC
V
High 0 7 V Signal level low
(HTL unipolar)
U
L
3)
Low 0 2 V
High signal level
(HTL bipolar)
2)
U
Hdiff
3 V
CC
V
Low signal level
(HTL bipolar)
2)
U
Ldiff
-V
CC
-3 V
High signal level
(SSI bipolar at X520 or X521/X531)
1)
U
Hdiff
2 5 V
Low signal level
(SSI bipolar at X520 or X521/X531)
1)
U
Ldiff
-5 -2 V
Signal frequency f
S
- 300 kHz
Edge clearance t
min
100 - ns
