Accessories
8.1 DRIVE-CLiQ cabinet gland
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
233
8.1.5 Installation
In order to install the DRIVE-CLiQ cabinet bushing, a cut-out must be made in the control
cabinet panel according to the diagram shown below.
5
Figure 8-3 Cut-out for the cabinet
