Cabinet design and EMC for components, Blocksize format
9.5 24 V DC Supply Voltage
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
261
9.5.5 Selecting power supply units
You are advised to use the devices in the following table. These devices meet the applicable
requirements of EN 60204-1.
Table 9- 4 Recommended SITOP Power
Rated output
current [A]
Phases Rated input voltage [V]
Working voltage range [V]
Short-circuit current [A] Order number
5 1 / 2 120 - 230/230 - 500
85 - 264/176 - 550 AC
Approx. 5.5 (power up),
typ. 15 for 25 ms (operation)
6EP1333-3BA00-8AC0
10 1 / 2 120 - 230/230 - 500
85 - 264/176 - 550 AC
Approx. 12 (power up),
typ. 30 for 25 ms (operation)
6EP1334-3BA00-8AB0
1 / 2 120/230
85 - 132/176 - 264 AC
6EP1336-3BA00-8AA0 20
3 230/400 to 288/500
320 - 550 3 AC
Approx. 23 (power up),
typ. 60 for 25 ms (operation)
6EP1436-3BA00-8AA0
1 / 2 120/230
85 - 132/176 - 264 AC
6EP1337-3BA00-8AA0 40
3 230/400 to 288/500
320 - 550 3 AC
Approx. 46 (power up),
typ. 120 for 25 ms (operation)
6EP1437-3BA00-8AA0
Table 9- 5 Recommendation for Control Supply Module
Rated output
current [A]
Input voltage range [V] Short-circuit current [A] Order number
20 3 380 V 3 AC -10% (-15% < 1 min)
to 480 V 3 AC+10%
DC 300 – 800
< 24 6SL3100-1DE22-0AA0
Refer also to Catalog PM21 or NC61.
WARNING
When using external power supplies, e.g. SITOP, the following points must be observed:
The ground potential M must be connected to the protective conductor terminal (DVC A).
The power supply must be installed close to the drive line-up.
Ideally, they should be installed on a common mounting plate. If different mounting plates are
used, their electrical interconnection must comply with the EMC installation guideline.
This installation guideline covers protection against electric shock, protection against fire, and
best possible electromagnetic compatibility.
