Mains connection and line-side power components
2.4 Using residual-current devices
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
35
2.4 Using residual-current devices
Selectively tripping, AC/DC-sensitive residual-current devices (type B) can be used in
addition to the overcurrent protection devices.
NOTICE
Residual-current devices have to be installed if the power supply conditions in terms of
short-circuit power and loop impedance at the infeed point are not such that the installed
overcurrent protection devices will trip within the prescribed period if a fault occurs. Since
TT systems do not generally meet this requirement, residual-current devices must always
be installed for this type of system.
Residual-current-operated circuit breakers (RCD)
Residual-current-operated circuit breakers (RCD) prevent an excessively high touch current
being maintained.
DANGER
Residual-current-operated circuit breakers alone are not permissible to provide protection
against direct and indirect contact.
When using residual-current-operated circuit breakers, it should be noted that
● It is only permissible to use a delayed tripping, selective AC/DC-sensitive residual-
current-operated circuit breaker, type B.
● The max. permitted grounding resistance of the "selective protective device" must be
observed (83 Ω max. for residual-current devices with 0.3 A rated differential current).
● Accessible parts of the Power Drive System and the machine must be connected to the
system's protective ground conductor.
● The shielded motor cable must not be longer than 50 m.
● A separate residual-current device must be used for each Power Module.
● Only one residual-current device may be connected in series (cascading is not
permitted).
● Switching elements (disconnector units, contactors) for connecting and disconnecting the
Power Drive System have a max. 35 ms delay time time between the closing/opening of
the individual main contacts.
If no residual-current-operated circuit breaker is used, touch protection can be ensured by
means of double insulation or by isolating the Power Module from the supply system via a
transformer.
