A.1 Spring-loaded terminals/screw terminal
Connectable conductor cross-sections of spring-loaded terminals
The type of spring-loaded terminal can be taken from the interface description of the
particular component.
Table A- 1 Spring-loaded terminals
Spring-loaded terminal type
Connectable conductor cross-
sections
Flexible
With wire end ferrule, without plastic sleeve
With wire end ferrule, with plastic sleeve
0.14 mm
2
to 1.5 mm
2
0.25 mm
2
to 1.5 mm
2
0.25 mm
2
to 0.5 mm
2
Insulation stripping length 9 mm
1
Tool Screwdriver 0.4 x 2.0 mm
Connectable conductor cross-
sections
Flexible 0.08 mm
2
to 2.5 mm
2
Insulation stripping length 8 to 9 mm
2
Tool Screwdriver 0.4 x 2.0 mm
Connectable conductor cross-sections of the screw terminal
Table A- 2 Screw terminal
Screw terminal
Connectable conductor cross-sections Rigid, flexible
With wire end ferrule, without plastic sleeve
With wire end ferrule, with plastic sleeve
0.08 mm
2
to 2.5 mm
2
0.5 mm
2
to 2.5 mm
2
0.5 mm
2
to 1.5 mm
2
Insulation stripping length 7 mm
Tool Screwdriver 0.6 x 3.5 mm
Tightening torque 0.5 to 0.6 Nm
