7
ENGLISH
32. Battery compartment cover – to fix the rechargeable battery
in its compartment.
33. Handset belt clip –use it if you want to wear the handset on
your belt.
34. Belt clip slot – to fix the belt clip on the handset.
Figure D
35. Battery compartment – for installing a 9V battery.
36. Battery compartment cover – to fix the battery in its compart-
ment.
37. Screw – to fix the battery compartment cover in place.
38. P-T switch – to change dialing mode (pulse/tone).
Figure E
39. Base unit AC adapter jack – to connect the AC adapter to the
base unit.
40. Telephone line jack – to connect the phone to the telephone line.
41. Base unit AC adapter– to connect the base unit to the 220V
AC mains.
42. Telephone line cord – to connect the phone to the telephone line.
In your package
1. Handset – 1
2. Base unit – 1
3. Phone line cord – 1
4. AC Adapter – 1
5. Rechargeable battery – 1
6. Battery compartment cover – 1
7. Handset belt clip – 1
8. 9V battery compartment cover – 1
9. Screw – 1
INSTALLING AND
CONNECTING
1. Insert the rechargeable battery [30] into the battery compartment
[31] on the handset [1], then close the battery compartment with
the cover [42] (see Fig. C).
2. Insert a 9V battery (6F22 type) into the battery compartment [35]
on the base unit [28] then close the compartment [35] with the
cover [36] and fasten the cover [36] with the screw [37] (see
Fig. D).
3. Connect one end of the phone line cord [42] to the phone line jack
[40] at the base unit [28] rear side, and the other end of the phone
line cord [42] to the phone line socket.
4. Insert the AC adapter [41] cable plug into its jack [39] at the base
unit [28] rear side. Insert the AC adapter [41] plug into a wall
outlet of your 220V electric mains (see Fig. E).
5. Place the handset [1] on the base unit [28] (see Fig. B). Before
initial use you should fully charge the battery for about 15 hours.
When you place the handset [1] on the base unit [29] for charging,
you should hear a short beep.
