Specifi cations
12
19 690 02 Rev. CKohlerEngines.com
TORQUE SPECIFICATIONS
3,5
PCV850, PCV860
Intake Manifold, Air Cleaner, Throttle Body
Intake Manifold Mounting Fastener 16.0 N·m (142 in. lb.)
Throttle Body to Intake Manifold Mounting Nut 6.8 N·m (60 in. lb.)
Throttle Body Mounting Stud (into intake manifold) 6.0 N·m (53 in. lb.)
Throttle Lever Adapter to Throttle Body Nut 6.8 N·m (60 in. lb.)
Air Cleaner Support Bracket to Throttle Body Bracket Fastener 10.2 N·m (90 in. lb.)
Air Cleaner Support Bracket to Air Cleaner Housing Fastener 5.8 N·m (51 in. lb.)
Fuel Injector Cap Fastener 7.3 N·m (65 in. lb.)
Fuse Holder Bracket to Manifold Screw 10.2 N·m (90 in. lb.)
Temperature/Manifold Absolute Pressure (TMAP) Sensor Fastener 7.3 N·m (65 in. lb.)
Connecting Rod
Cap Fastener (torque in increments) 11.6 N·m (103 in. lb.)
Crankcase
Breather Cover Fastener 11.3 N·m (100 in. lb.)
Breather Reed Retainer Fastener 11.3 N·m (100 in. lb.)
Oil Fill Tube Screw 7.7 N·m (68 in. lb.)
Cylinder Head
Fastener (torque in 2 increments)
Head Bolt fi rst to 23.7 N·m (210 in. lb.)
fi nally to 46.9 N·m (415 in. lb.)
Rocker Arm Stud 24.0 N·m (212 in. lb.)
Rocker Pivot Set Screw 7.8 N·m (69 in. lb.)
Debris Screen
Fastener 9.9 N·m (88 in. lb.)
Flywheel
Retaining Screw 71.6 N·m (53 ft. lb.)
Fixed Guard
Fastener 1.4 N·m (12 in. lb.)
Fuel Vaporizer/Regulator/Lock-Off
Regulator to Bracket Nut 12.4 N·m (110 in. lb.)
Regulator Bracket Mounting Screw 11.9 N·m (105 in. lb.) into new holes
7.8 N·m (69 in. lb.) into used holes
Lock-Off Valve Body Nut 6.5 N·m (57 in. lb.)
Lock-Off Valve Body 20 N·m (177 in. lb.)
Fuel Outlet Fitting Mounting Screws 2.9 N·m (26 in. lb.)
Fuel Inlet Fitting 20 N·m (177 in. lb.)
Fuse Cover (Optional)
Bracket Stud 9.9 N·m (88 in. lb.)
Retaining Nut 9.9 N·m (88 in. lb.)
Retaining Screw 9.9 N·m (88 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
