Specifi cations
8
19 690 02 Rev. CKohlerEngines.com
Engine Dimensions-Starter Side
A
B
C
D
E
F
G
H
I
J
K
A Rectifi er-Regulator B
Electronic Control Unit
(ECU)
C
Customer Ground
Location
M8 X 1.25 mm
20 mm (0.79 in.)
Deep
D 34.6 mm (1.36 in.)
E 207 mm (8.15 in.) F
Oil Drain Plug
3/8 in. NPTF
G 13 mm (0.51 in.) H Mounting Hole "A"
I 33.3 mm (1.31 in.) J
Customer Interface
Connector
K
Engine Mounting
Surface
