KSB Etanorm ETN 065-040-160 [27/40] Centrifugal pumps with shaft seal
![KSB Etanorm ETN 080-065-250 [27/40] Centrifugal pumps with shaft seal](/views2/1603700/page27/bg1b.png)
Flange drilled to: ASME B 16.1, Class 125 or ASME B 16.5, Class 150
Flange dimensions [mm]
Nominal size Standard
ASME B 16.1 or ASME B 16.5
Material
B, C, G, S
Class 125 or Class 150
∅ K Number and ∅ of holes (∅ L)
25/ NPS 1 79,2 4 × ∅15,7
32/ NPS 1 1/4 88,9 4 × ∅15,7
40/ NPS 1 1/2 98,6 4 × ∅15,7
50/ NPS 2 120,7 4 × ∅19,1
65/ NPS 2 1/2 139,7 4 × ∅19,1
80
26)
/ NPS 3
152,4 4 × ∅19,1
100/ NPS 4 190,5 8 × ∅19,1
125/ NPS 5 215,9 8 × ∅22,4
150/ NPS 6 241,3 8 × ∅22,4
200/ NPS 8 298,5 8 × ∅22,4
NPS for DN 80 flange drilled to ASME
Size Bearing
bracket
Material variant
G, GB, GC B S, SB, SC C
DN 1
ASME 125
DN 2
ASME 125
DN 1
ASME 125
DN 2
ASME 125
DN 1
ASME 125
DN 2
ASME 125
DN 1
ASME 125
DN 2
ASME 125
080-065-125 25 NPS 4 NPS 2 1/2 - - - - NPS 4 NPS 2 1/2
080-065-160 25 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2
080-065-200 25 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2
080-065-250 35 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2
080-065-315 35 NPS 4 NPS 2 1/2 - - NPS 4 NPS 2 1/2 NPS 4 NPS 2 1/2
Scope of supply
Depending on the model, the following items are included in
the scope of supply:
Scope of supply
Scope of supply Region
Pump A, B, C, D
Baseplate A, B, C, D
Coupling A, B, C, D
Coupling guard A, B, C, D
Motor A, C, D
26)
On sizes 080-065-125, 080-065-160, 080-065-200, 080-065-250, 080-065-315 flanges DN 80 (NPS 3) are drilled to NPS 4. Also
see the table on NPS for DN 80.
Centrifugal Pumps with Shaft Seal
Standardised Water Pumps
Etanorm
27
