KSB Etanorm ETN 065-040-160 [29/40] Centrifugal pumps with shaft seal
![KSB Etanorm ETN 050-032-250 [29/40] Centrifugal pumps with shaft seal](/views2/1603700/page29/bg1d.png)
Part No. Description Part No. Description
411.77/.78 Axial seal ring Connections:
433 Mechanical seal 1M Connection for pressure gauge
502.01/.02
Casing wear ring
29)
6B Fluid drain
523 Shaft sleeve 6D Fluid priming and venting
550.95
30)
Disc 8B Leakage drain
27)
For casing materials S and C only
28)
For shaft units 55 and 60 only
29)
Optional for casing material C
30)
For shaft unit 25 only
Centrifugal Pumps with Shaft Seal
Standardised Water Pumps
Etanorm
29
