6. OPERATION

Install the device on a firm and stable surface or tripod.

Move the switch bar to select the required operation mode:

1) Unlocked mode (self-leveling)

Move the switch bar to position ON.

The laser level will switch on.

Short press to switch on required laser lines.

Short press to switch on/off the pulse mode.

Move the switch bar to position OFF to switch off the laser level.

2) Locked mode (projection of inclined planes)

The switch bar is in position OFF.

Press and hold during 3 seconds to switch on the laser.

Long press to switch on required laser lines.

After all possible combinations of lines are switched on, the next long

press will switch off the laser level.

Press and hold during 3 seconds to switch on/off the pulse

mode.

Note: To increase the operating time and avoid the risk of

unintentional blinding switch on the laser only before start operation.

If operated near objects or airflows different from the environment

temperature the laser line may tremble due to heterogeneity of the

atmosphere. The longer the distance, the more trembling can be

observed.

The width of the laser line increases with the increasing of the

operating distance. The marking should be made along the axis of the

laser line. For maximum accuracy, use the middle portion of the laser

line.

It should be noted that the shape of the laser line on the object’s

surface (e.g. walls, ceilings) depends on the curvature and slope of the

surface relative to the laser plane.
