Grillo G 46 [10/56] Putting the machine into service

Translation of the original instructions

WARRANTY

The guarantee is given in compliance with the current law. The Grillo dealer will supply the client

with a copy of the registration card of the machine, which they will print from the Grillo website. For

the engine, the guarantee of the relative manufacturers apply.

ORDERING SPARE PARTS

Always state the machine serial number and the code number of the part to be replaced. Contact

your local dealer. Our address is:

GRILLO S.p.A.

Via Cervese 1701 - 47521 CESENA (FC) - ITALY

Tel. 0039 / 0547 / 633111 - Fax 0039 / 0547 / 632011

Web site: www.grillospa.it - E-mail: grillo@grillospa.it

TECHNICAL SPECIFICATIONS G46

ENGINE:

- HONDA GX200 OHV, 196 cc 5,5 HP (@ 3600 r.p.m.) one-cylinder, petrol.

- KOHLER 3000 OHV 196cc 5 HP (@ 3600 r.p.m.) one-cylinder, petrol.

STARTER: recoil starter.

FUEL TANK: 3,1 Litres.

CLUTCH: active and cone clutch.

GEARBOX: gears in oil bath with 2 gears, 1 forward gear + 1 reverse gear.

INVERTER: rapid inverter through lever.

P.T.O: at 965 r.p.m. in anti clockwise rotation.

SAFETY DEVICES: active coupling, reverse speed – PTO cut out.

HANDLEBAR: with height and side adjustment.

ROTARY TILLER: standard 500 mm with contra-rotating tines.

WORKING DEPTH: max.130 mm, adjustable in 5 different positions.

SPEED WITH 4.00-8 TRACTOR WHEELS: forward gear 1,6 km/h – reverse gear 1,6 km/h.

EXTERNAL DIMENSION WITH 4.00 – 8 WHEELS: 480 mm.

ATTACHMENTS: furrower behind the tiller.

WEIGHT: 95 kg

PUTTING THE MACHINE INTO SERVICE

1) Check that the machine has not been damaged in transit. Check that all components necessary

to the assembling of the machine have been included.

2) Mount the handlebar column (fig. 1). Tighten the two nuts no. 50122 (fig. 1) paying attention not

no block the rotation of the handlebar and insert the spacer no. 13668. Connect the spring of the

clutch cable to the clutch lever located on the gearbox (fig. 4, no. 18) and insert the steel tip into

the appropriate position (fig. 4, no. 18A).

3) Pull the machine out of the packaging, paying close attention not to damage levers and cables.

Use a lifting machine (minimum lifting capacity: 200 kg). Before putting the machine on the ground,

mount the wheels using the appropriate screws (fig. 1).

4) WITH THE ENGINE OFF: the user can put the wheel shaft into neutral position by turning the

lever left (fig. 3A, no. 12) to make transport easier.

5) Add engine oil (see engine manual).
