HOW TO START THE MACHINE

Keep the engine at low r.p.m., engage the implement by pressing the lever no. 3 (fig. 2); accelerate

properly. The machine will start moving by pressing first the lever (fig. 2, no.7) and subsequently the lever

(fig. 2, no.1). Releasing the lever no. 1 (fig. 2) the machine stops. Releasing the lever no. 3 (fig. 2) the

attachment stops working. Using the lever n. 2 (fig. 2) the machine goes backward (always keep the

engine at low r.p.m.). It is necessary to press the lever n.1 (fig. 2) too.

END OF WORK

When work is ended, to stop the engine bring the throttle lever to the minimum (fig. 2 no. 5) and press the

 the fuel tap is open;

 the choke is ON when the engine is cold (fig. 7 no. 1)

 fuel gets to the carburettor;

 the vent hole on the tank plug is not obstructed;

 the air filter is clean (fig. 5 – fig. 6)

 current gets to the spark plug (please refer to the relative engine manual). If current does not

arrive, after checking the electric cables have no defects and the plug is clean, change the plug taking

care not to buy another one with the same heat rating. If this attempt also should turn out to be useless,

the failure must be searched in the magneto flywheel; at this point it is advisable to go to the nearest

Service Centre.

- When carrying out maintenance operations and/or when the machine is tilted without safety

locks or supports, never leave it unguarded in places where inexperienced people and children

could have easy access to it.

- Protect the environment: carefully dispose of used oils, petrol and any other pollutant product!

- Effective maintenance and correct lubrication help to keep the machine fully efficient.

LUBRICATION: do the following operations with the machine in horizontal position. N.B.: the oil change

must be effected with warmed up machine in order to help the total drainage.

ENGINE OIL

carefully follow the instruction of the user's manual. It is however necessary to check the oil level every 4

hours taking the plug off (fig. 8, no.1) and checking that the oil reaches the hole border. Change oil within

MAINTENANCE

After the first working hours, it might be necessary to check and adjust the wheel cable and the reversing

device cable acting on the adjuster situated on the handle. The quick coupling be always clean and

greased. To remove the fairing pull upward.
