PNP SILICON PLANAR TRANSISTORS
2N4234, 2N4235
2N4236
TO-39
Metal Can Package
General Purpose Transistor
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
SYMBOL
2N4234
2N4235
UNIT
Collector Emitter Voltage
V
CEO
40 60 V
Collector Base Voltage
V
CBO
40 60 V
Emitter Base Voltage
V
EBO
7.0 V
Base Current
I
B
200 mA
Collector Current Continuous
I
C
1.0 A
Power Dissipation @ T
a
=25ºC P
D
1.0 W
Derate Above 25ºC
5.7 mW/ ºC
Power Dissipation @ T
c
=25ºC P
D
6.0 W
Derate Above 25ºC
34 mW/ ºC
Operating and Storage Junction
Temperature Range
T
j
, T
stg
- 65 to +200 ºC
THERMAL CHARACTERISTICS
Junction to Case
R
th (j-c)
29 ºC/W
ELECTRICAL CHARACTERISTICS (T
a
=25ºC unless specified otherwise )
DESCRIPTION
SYMBOL
TEST CONDITION
2N4234
2N4236
UNIT
Collector Emitter Voltage
V
CEO
I
C
=1mA, I
B
=0
40 60 80 V
Collector Cut Off Current
I
CEO
V
CE
=30V, I
B
=0
1.0 mA
V
CE
=40V, I
B
=0
1.0 mA
V
CE
=60V, I
B
=0
1.0
mA
Collector Cut Off Current
I
CEX
V
CE
=40V, V
EB
=1.5V
0.1 mA
V
CE
=60V, V
EB
=1.5V
0.1 mA
V
CE
=80V, V
EB
=1.5V
0.1 mA
T
C
=150ºC
V
CE
=30V, V
EB
=1.5V
1.0 mA
V
CE
=40V, V
EB
=1.5V
1.0 mA
V
CE
=60V, V
EB
=1.5V
1.0 mA
MIN
TYP
MAX
Collector Cut Off Current
I
CBO
V
CB
=Rated V
CBO
, I
E
=0
0.1 mA
Emitter Cut Off Current
I
EBO
V
EB
=7V, I
C
=0
0.5 mA
DC Current Gain
*h
FE
I
C
=100mA, V
CE
=1V
40
I
C
=250mA, V
CE
=1V
30 150
I
C
=500mA, V
CE
=1V
20
I
C
=1A, V
CE
=1V
10
*Pulse Test: Pulse Width
<
300
µµ
s, Duty Cycle
<
2%
2N4234_4236Rev_1 121004E
2N4236
80
80
Continental Device India Limited
Data Sheet Page 1 of 4
Continental Device India Limited
An ISO/TS 16949 and ISO 9001 Certified Company
