RANGE
MODEL CODE
RIELLO 7200.200 V PLUS 4030203
RIELLO 7200.300 V PLUS 4030205
RIELLO 7200.430 V PLUS 4030207
RIELLO 7200.550 V PLUS 4030209
RIELLO 7200.800 V PLUS 4030211
RIELLO 7200.1000 V PLUS 4030221
ACCESSORIES
For a complete list of accessories and details of their compatibility,
refer to the Catalogue.
ENGLISH
Dear Customer,
Thank you for choosing a
R
storage cylinder. You have
purchased a modern, quality product that is designed to give
dependable and safe service and to provide comfort in the
home for many years to come. Arrange for your
R
storage
cylinder to be serviced regularly by an authorised
R
service
centre. Their personnel are specially trained to keep your storage
cylinder efcient and cheap to run.
R
service centres also
stock any original spare parts that might be required.
This manual contains important instructions and precautions
that must be observed to ensure the trouble-free installation
and efcient functioning of your
R
storage cylinder.
Please accept our renewed thanks for your purchase,
Riello S.p.A.
CONFORMITY
R
storage cylinders conform to DIN 4753-3 and UNI EN 12897
standards.
9
This product must only be used for the purpose for which it
is designed and made, as specied by
R. R declines
all responsibility, contractual or other, for damage to
property or injury to persons or animals caused by improper
installation, adjustment, maintenance or use.
