INSTALLER

10 UNPACKING THE PRODUCT

MODELS 7200 V Plus 200 to 550

R 7200 V Plus storage cylinders are delivered in a single

package, protected by a cardboard box on a wooden pallet.

The following items are delivered in a plastic bag inside the

packaging:

− Instruction manual

− Certicate of warranty and label with bar code

− Spare parts catalogue

− Hydraulic test certicate

MODEL A B H

Weight

(Kg)

200 700 700 1480 95

300 700 700 1980 125

430 850 850 1790 175

550 850 850 2130 195

MODELS 7200 V Plus 800 - 1000

R 7200 V Plus storage cylinders are delivered in a single

package, protected by a plastic bag inside a protective foam

rubber wrapping and supported by a wooden pallet.

The following items are delivered in a plastic bag inside the

packaging:

− Instruction manual

− Warranty certicate and barcode label

− Spare parts catalogue

− Hydraulic test certicate

− 4 adjustable feet

The second anode for installation instead of the inspection

ange is supplied separately and must be tted by the

installer. The rst anode comes pre-installed in the top

ange (vertical position).

The instruction manual is an integral part of the solar storage

cylinder. Once located, read it thoroughly and keep it safe.

MODEL A B H

Weight

(Kg)

800 1040 1040 2025 225

1000 1040 1040 2350 260

11 HANDLING

MODELS 7200 V Plus 200 to 550

Make sure that any lifting equipment is of adequate capacity to

lift and move the storage cylinder.

Remove the brackets (1) to free the storage cylinder.

To lift the storage cylinder, remove the plug (2) and screw an

eyebolt (Ø 3/4”) of suitable capacity for the weight of the cylinder

into the hole (3).

Fit the feet provided into the holes in the bottom of the storage

cylinder and adjust as necessary to compensate for any

unevenness in the oor.

Installer
