7

GENERAL

GENERAL

7 WATER CIRCUIT

TYPICAL INSTALLATION SCHEMATIC

DHW production system with one storage cylinder

EAF

800 V PLUS

1000 V PLUS

RC

UAC

1

2

3

1

1 7

7

18

9

11

(*)

10

10

8

1

1

1

1

PRIMARY CIRCUIT

Outlet

Inlet

4

5

6

6

SB

1

4

5

6

DHW production system with two storage cylinders

200 V PLUS 300 V PLUS

EAF

SB

UAC

1

2

3

1

1 7

7

18

8

1

1

1

1

1

4

5

6

PRIMARY CIRCUIT

Outlet

Inlet

6

9 9

10

10

RC RC

1 Disconnect valves

2 Pressure reducer

3 Water softener lter

4 Safety valve

5 Drain

6 Expansion vessel

7 Pump

8 Non-return valve

9

R 7200 V Plus storage cylinder

10 Central heating system manifolds

11 Alternative position for rst magnesium anode

UAC Hot water outlet

EAF Domestic cold water inlet

RC Recirculation

SB Storage cylinder drain

(*) By moving the rst magnesium anode (installed as

standard in the vertical position) to tting (11), an

expansion vessel/safety system can be connected directly

to the top ange.

Note! The above schematic is purely indicative.

9

R 7200 V Plus storage cylinders are delivered without

a boiler heating pump. A suitably rated pump must be

provided and installed separately.

9

The domestic hot water system MUST INCLUDE an expansion

vessel, safety valve, automatic vent valve and storage

cylinder drain cock.

9

The safety valve must be connected to a suitable

collection and drain system. The manufacturer declines all

responsibility for damage caused by water escaping from

the safety valve.

9

The choice of system components and the method of their

installation are left up to the heating engineer installing the

system. Installers must use their expertise to ensure proper

installation and functioning in conformity to all applicable

legislation.

9

Circuits lled with anti-freeze must be tted with water

disconnectors.
