ELECTRICAL SPECIFICATIONS
EWAD C
-
XL
830
890
990
C10
C11
C13
C12
760
MODEL
POWER SUPPLY
Phases
Nr
3
3
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
400
400
Voltage tolerance Minimum
%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
Voltage tolerance Maximum
%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
UNIT
Maximum starting current
A
618
657
657
923
970
1029
1029
1029
Nominal running current cooling
A
387
423
463
511
559
607
667
686
Mximum running current
A
510
561
605
672
731
811
875
875
Maximum current for wires sizing
A
556
612
660
733
797
884
955
955
FANS
Nominal running current cooling
A 48 56 56 64 64 80
80
80
COMPRESSORS
Phases
Nr
3
3
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
400
400
Voltage tolerance Minimum
%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
Voltage tolerance Maximum
%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
Maximum running current
A
231
231
231
274
274
274
274
333
333
333
333
398
398
398
398
398
Starting method
---
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
EWAD C-XL
H15
C16
C17
C18
C19
C21
C20
H14
MODEL
POWER SUPPLY
Phases
Nr
3
3
3
3
3
3
3
3
Frequency
Hz 50 50 50 50 50 50
50
50
Voltage V 400 400 400 400 400 400 400 400
Voltage tolerance Minimum
%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
Voltage tolerance Maximum % +10% +10% +10% +10% +10% +10% +10% +10%
UNIT
Maximum starting current
A
1072
1085
1268
1328
1387
1387
1430
1472
Nominal running current cooling
A
731
778
835
885
934
984
1018
1059
Mximum running current
A
929
982
1096
1168
1241
1313
1366
1419
Maximum current for wires sizing
A
1013
1072
1196
1275
1354
1432
1491
1549
FANS
Nominal
running current cooling
A
80
80
96
104
112
120
120
120
COMPRESSORS
Phases
Nr
3
3
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
400
400
Voltage tolerance Minimum
%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
-
10%
Voltage tolerance Maximum
%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
+10%
Maximum running current
A
398
451
451
451
333
333
333
333
333
398
398
398
333
398
398
398
398
398
451
451
451
398
Starting method
---
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
Y
-
∆
