Daikin EWAD830C-SS [93/96] Technical specifications

General

The chiller will be designed and manufactured in accordance with the following European directives:

• Construction of pressure vessel 97/23/EC (PED)

To avoid any losses, the unit will be tested at full load in the factory (at the nominal working conditions and water tempera

chiller will be delivered to the

comply with the manufacturer’s instructions for rigging and handling equipment.

The unit will be able to start up and operate (as standard) at full load with:

- outside air temperature from ............... °C to ............... °C

• Heat exchanger entering water temperature in cooling mode : ............... °C

• Heat exchanger leaving water temperature in cooling mode : ............... °C

• Heat exchanger water flow : ............... l/s

• Nominal outside working ambient temperature in cooling mode : ............... °C

Operating voltage range should be 400V ±10%, 3ph, 50Hz, voltage unbalance maximum 3%, without neutral conductor and shall onl

have one power connection point.

Unit description

components, discharge line shut-off valve, control system and all components necessary for a safe and stable unit operation.

The chiller will be factory assembled on a robust base frame made of galvanized steel, protected by an epoxy paint.

Sound level and vibrations

………dB(A). The sound pressure levels must be rated in accordance to ISO 3744 (other types of rating can not be used).

Vibration on the base frame should not exceed 2 mm/s.

Dimensions

Unit dimensions shall not exceed following indications:

- Unit length ............... mm

gaterotors’ contact elements shall be constructed of composite material designed for extended life. Electrical motor shall be 2-pol

semi-hermetic, squirrel-cage induction type and cooled by suction gas.

• The oil injection shall be used in order to get high EER (Energy Efficiency Ratio) also at high condensing pressure and low

pressure levels in each load condition.

• The compressor shall be provided with a built in, high efficiency, mesh type oil separator and oil filter.

• Refrigerant system differential pressure shall provide oil injection on all moving compressor parts to correctly lubricate

the oil from compressor to heat exchanger and viceversa is not allowed.

• The compressor shall be direct electrical driven, without gear transmission between the screw and the electrical motor.

• The compressor casing shall be provided with ports to realize economized refrigerant cycles.

• The compressor must be protected by a temperature sensor

high winding temperature.

• The compressor shall be equipped with an electric oil heater.

• The compressor shall be fully field serviceable. Compressor that must be removed and returned
