• Chillers • R-407C • EWAP-AJYNN
1
5
• Hydronic Systems • Chillers
30
5 Capacity tables
5 - 3 Heat recovery ratings
EWAP-AJYNN
EWAP-AJYNN/A
Standard
unit size
/A
unit size
LWPR
45 50 55
HC HC HC
800 850
Leaving chilled water temperature 7°C
Δ
T 5°C – Air temperature 35 °C
165 133 99
900 900
181 146 108
950 950
197 160 118
C10 C10
212 172 127
C11 C11
228 185 137
C12 C12
247 200 148
C13 C13
263 213 158
C14 C14
279 226 168
C15 C15
295 239 177
C16 C16
311 252 187
C17 C17
326 264 196
C18 C18
342 277 205
SYMBOLS
HC: Heating Capacity (kW)
LWPR: Leaving desuper-heaters water temperature (°C)
