• Chillers • R-407C • EWAP-AJYNN
1
10
• Hydronic Systems • Chillers
38
10 Hydraulic performance
10 - 1 Water pressure drop curve evaporator
EWAP-AJYNN
EWAP-AJYNN/A
C16 - C17 - C18 - C16/A - C17/A - C18/A
C13 - C14 - C15 - C13/A - C14/A - C15/A
C12/A
C10 - C11 - 900/A - 950/A
C12
C10/A - C11/A
900 - 950 - 850/A
800
110
100
90
80
70
60
50
40
30
20
10
Pressure drop (kPa)
flow rate (l/s)
10 20 30 40 50 60 70 80 90 100 200
