Daikin EWAPC11AJYNN [37/41] Chillers r 407c ewap ajynn
![Daikin EWAPC11AJYNN [37/41] Chillers r 407c ewap ajynn](/views2/1659202/page37/bg25.png)
3
1
9
• Hydronic Systems • Chillers
37
• Chillers • R-407C • EWAP-AJYNN
9 Operation range
EWAP-AJYNN
EWAP-AJYNN/A
NOTE
1 Max ambient temperature are referred to units working at full load. With higher temperatures the chillers will unloading.
2 When air temperature is lower then +10°C you need the fan speed control device. It allows the unit working with air temperature down to –18°C.
Unit version
STANDARD OPRN-OPLN
Max ambient temperature (1)
°C
42 38
Min ambient temperature
°C
+10 (2) +10 (2)
Max leaving evaporator water temperature
°C
+10 +10
Min leaving evap. water temp.(without glycol)
°C
+4 +4
Min leaving evap. water temp.(with glycol)
°C
-8 -8
Max evaporator ΔT
°C
66
Min evaporator ΔT
°C
44
Unit version
STANDARD OPRN-OPLN
Max ambient temperature (1)
°C
46 42
Min ambient temperature
°C
+10 (2) +10 (2)
Max leaving evaporator water temperature
°C
+10 +10
Min leaving evap. water temp.(without glycol)
°C
+4 +4
Min leaving evap. water temp.(with glycol)
°C
-8 -8
Max evaporator ΔT
°C
66
Min evaporator ΔT
°C
44
