ESIE03-03 General Outline

Part 1 – System Outline 1–5

(1)

: The table below contains the minimum water volume settings.

(2)

: The sound power level is an absolute value that does not depend on the surroundings or the

distance (ISO 9614). It cannot be measured in the field

Nominal conditions The nominal conditions are as follows:

■ Entering/leaving evaporator water temperature 12/7°C, ambient air temperature 35°C,

■ Entering/leaving condenser water temperature 30/35°, ambient temperature 7°C DB/6°C WB

■ Power input is total input: Compressor + control circuit + pumps.

Operation range The nominal operation range covers a leaving evaporator water temperature from 5°C (-5°C/ -10°C

with ZH/ ZL option) to 20°C and a leaving condenser water temperature from 20°C to 55°C.

Sound power level

(2)

64 dB

Safety devices

■ Low-pressure switch

■ High-pressure switch

■ Evaporating temperature protection

■ Discharge temperature protection

■ Outlet water temperature protection

■ Compressor motor overcurrent relay

■ Anti-recycling and guard timer

■ Digital display controller with electronic temperature control

■ Reverse phase protector

■ Internal fuses.

Setting EUW5-10KZW1

The minimum water volume for standard thermostat difference setting 3 K

For reduced setting multiply this water volume by 3/new setting

Minimum allowable setting 0.1 K

Model EUW5KZW1 EUW8KZW1 EUW10KZW1
