General Outline ESIE03-03
1–4 Part 1 – System Outline
3
11
4
5
1.2 Technical Specifications: EUW5-10KZW1
Technical
specifications
The table below contains the technical specifications.
Model EUW5KZW1 EUW8KZW1 EUW10KZW1
Nominal cooling
capacity
13.0 kW 21.5 kW 28.0 kW
Nominal cooling input 3.71 kW 5.96 kW 7.76 kW
Capacity steps 1
Compressor
Type Hermetically sealed scroll
Speed 2900 rpm
No. x model 1 x JT140BF-YE 1 x JT212DA-YE 1 x JT300DA-YE
Evaporator
Type Brazed plate-heat exchanger
Min.water volume in
the system
(1)
62 l 103 l 134 l
No. x model SWEP V27
Water flow rate Min.: 19 l/min
Max.: 75 l/min
Min.: 31 l/min
Max.: 123 l/min
Min.: 40 l/min
Max.: 161 l/min
Nominal water flow 37 l/min 62 l/min 80 l/min
Insulation material Polyethylene foam
Condenser
Type Brazed plate-heat exchanger
No. x model SWEP B27
Water flow rate Min.: 24 l/min
Max.: 95 l/min
Min.: 39 l/min
Max.: 157 l/min
Min.: 51 l/min
Max.: 203 l/min
Nominal water flow 48 l/min 78 l/min 102 l/min
Piping connections
Evap. water in/outlet
Cond. water in/outlet
FBSP 25
Refrigerant circuit
Refrigerant type R-407C
Refrigerant charge 1.2 kg 2.0 kg 2.3 kg
Refrigerant control Thermostatic expansion valve
Oil type Idemitsu FVC 68D
Dimensions
(h x w x d)
600 x 600 x 600 mm
Weight
Machine weight 113 kg 150 kg 160 kg
Casing
Material Polyester coated / galvanised steel plate
Colour Ivory white / Munsell code 5Y7.5/1 / ± RAL 7044
