General Outline ESIE03-03
1–14 Part 1 – System Outline
3
11
4
5
1.7 Technical Specifications: EUWL24KZW1
Technical
specifications
The table below contains the technical specifications.
Model EUWL24KZW1
Nominal cooling capacity 62.4 kW
Nominal cooling input 20.4 kW
Capacity steps 2
Compressor
Type Hermetically sealed scroll
Speed 2900 rpm
Crankcase heater 2 x 33 W
No. x model 2 x JT335DA-YE
Evaporator
Type Brazed plate-heat exchanger
Min.water volume in the system
(1)
31 l
No. x model SWEP DV47
Water flow rate Min.: 89 l/min
Max.: 358 l/min
Nominal water flow 179 l/min
Insulation material Polyethylene foam
Piping connections
Evap. water in/outlet FBSP 40
Evaporator drain purge Field installed
Discharge connection 2 x 19.1 mm flare
Liquid connection 2 x 12.7 mm flare
Max. lenght/circuit
(3)
50 m
Max. height/circuit
(3)
30 m
Refrigerant circuit
Refrigerant type R-407C
Refrigerant charge N
2
holding charge
Refrigerant control Thermostatic expansion valve
Oil type Idemitsu FVC 68D
Refrigerant charge formula
(4)
See 2 x 12HP
Dimensions
(h x w x d)
600 x 600 x 1200 mm
Weight
Machine weight 274 kg
Casing
Material Polyester coated / galvanised steel plate
Colour Ivory white / Munsell code 5Y7.5/1 / ± RAL 7044
Sound power level
(2)
74 dB
