ESIE03-03 Introduction
v
3
4
5
Part 0
1 Introduction
1.1 About This Manual
Target group This service manual is intended for and should only be used by qualified engineers.
Purpose of this
manual
This service manual contains all the information you need to carry out the necessary repair and
maintenance tasks for the EUW(L)5-24KZW1.
EUW5-24KZW1 The Daikin EUW5-24KZW1 water-cooled water chillers:
■ Are designed for indoor installation.
■ Are used for cooling and heating applications.
■ Are available in seven standard sizes with nominal cooling capacities ranging from 13 kW to
65 kW.
EUWL5-24KZW1 The Daikin EUWL5-24KZW1 water/air-cooled water chillers:
■ Are designed for indoor installation.
■ Are used for cooling and heating applications.
■ Are available in seven standard sizes with nominal cooling capacities ranging from 12.1 kW to
62.4 kW.
Before starting up
the unit
Before starting up the unit for the first time, make sure it has been properly installed. See "Pre-Test
Run Checks" on page 4–3.
