Features

2.6. Display Subsystem

This section includes:

● Display engine

● Video output

Display Engine

● Four movable layers, each layer size up to 2048x2048 pixels

● Ultra-Scaling engine

–

Support four-tap scale filter in both horizontal and vertical

–

Support input size up to 1920x1920 resolution and output size up to 1280x1280 resolution

● Support multiple image input formats: mono 1/2/4/8bpp, palette 1/2/4/8bpp, 6/24/32bpp color,

YUV444/420/422/411

● Support alpha blending / color key / gamma

● Support output color correction: luminance / hue / saturation, etc

● Support Saturation Enhancement and Dynnmic Range Control

● Support realtime write back function

Video Output

● Support CPU / Sync RGB / LVDS LCD interface up to 1280x800 resolution

● Support 1/2/4-lane MIPI DSI interface up to 1280x800 resolution

–

Support MIPI DSI V1.01 and MIPI D-PHY V1.00

–

Support command mode and video mode (non-burst mode with sync pulses, non-burst mode with sync event

and burst mode)

● Support RGB666 dither function
