OLIMEX A33-OLINUXINO-N8G [7/35] Memory subsystem
![OLIMEX A33-OLINUXINO-N8G [7/35] Memory subsystem](/views2/1659514/page7/bg7.png)
Support block size from 1 to 65535 bytes
Support Memory Dynamic Frequency Scale
Boot ROM
A33 Datasheet
Copyright © 2014 Allwinner Technology Co., Ltd. All Rights Reserved.
Page 7
Features
2.3. Memory Subsystem
This section consists of:
●
● SDRAM
● NAND Flash
● SD/MMC interface
Boot ROM
● Support system boot from Raw NAND, eMMC NAND, SPI NOR Flash, and SD/TF card
● Support system code download through USB DRD(Dual Role Device)
SDRAM
● Support 2GB address space
● Support 16-bit bus width
●
Compatible with JEDEC standard DDR3 /DDR3L SDRAM
NAND Flash
● Comply to ONFI 2.3 and Toggle 1.0
● Support 64-bit ECC per 512 bytes or 1024 bytes
● Support 8-bit Raw NAND flash controller sharing pin with eMMC
●
Support 2 CE and 2 RB signals
●
Support SLC/MLC/TLC NAND and EF-NAND
SD/eMMC Interface
● Comply to eMMC standard specification V4.41, SD physical layer specification V2.0, SDIO card specification
V2.0
● Support 4/8-bit bus width
● Support HS/DS bus mode
● Support 3 SD/eMMC controllers
● Support SDIO interrupt detection
●
Support two ranks
●
Support 16 address signal lines and 3 bank signal lines
●
●
Support CRC generation and error detection
●
