A33 Datasheet
Copyright © 2014 Allwinner Technology Co., Ltd. All Rights Reserved.
Page 11
Features
2.7. Video Engine
Video Decoding
● Support video playback up to 1920x1080@60fps
● Support multi-format video playback, including MPEG1/2, MPEG4 SP/ASP GMC, WMV9/VC1,
H.263 including Sorenson Spark, H.264 BP/MP/HP, VP8, WMV9/VC-1, JPEG/MJPEG, etc
Video Encoding
● Support H.264 HP video encoding up to 1920x1080@60fps
● JPEG baseline: picture size up to 4080x4080
● Support Alpha blending
● Support thumb generation
● Support 4x2 scaling ratio: from 1/16 to 64 arbitrary non-integer ratio
