![OLIMEX A33-OLINUXINO-N8G [6/35] Cpu architecture](/views2/1659514/page6/bg6.png)
A33 Datasheet
Copyright © 2014 Allwinner Technology Co., Ltd. All Rights Reserved.
Page 6
Features
2
FEATURES
2.1. CPU Architecture
The A33 platform is based on quad-core Cortex
TM
-A7 CPU architecture.
● ARMv7 ISA standard instruction set plus Thumb-2 and Jazeller RCT
● NEON with SIMD and VFPv4 support
● Support hardware virtualization
● Support LPAE
● Support 4GB address space
● Support 256KB L1 cache and shared 512KB L2 cache
● Support DVFS with independent power domain
2.2. GPU
● Mali400MP2 GPU
● Support OpenGL ES 2.0 / OpenVG 1.1 standard
