Pin Description

BALL# Pin Name

Default

Function

Type Reset State

Default Pull

Up/Down

Buffer

Strength (mA)

CLOCK

R17 X32KIN - A - - -

R16 X32KOUT - A - - -

R15 X32KFOUT - A - - -

M13 RTCVIO - P - - -

M12 VCC-RTC - P

- - -

U4 X24MIN - A - - -

T4 X24MOUT - A - - -

M5 VCC-PLL - P - - -

POWER

M8 VCC-EFUSE - P - - -

M14 VDD-CPUS - P - - -

E5,E6,E7,F5,F6,

F7,G5,G6

VDD-CPU - P - - -

E8,E9,E10,K6,

L6,M6,M7,N8

N9,N10

VDD-SYS - P - - -

E11,E12,F11

F12,G12

VCC-IO - P - - -

F8,F9,F10,

G7,G8,G9,G10,

G11,H7,H8,

H9,H10,H11,

H12,J7,J8,J9,

J10,J11,J12

K7,K8,K9,K10,

K11,K12,

L8,L9,L10,

L11,M9,M10

GND - G - - -
