The Digital Controller ESIE07-04
2–30 Part 2 – Functional Description
3
1
2
4
5
Refrigerant
temperatures
This screen shows the refrigerant temperatures.
Load request This screen shows the load request of this circuit.
Comp 2 information The following screens will appear for compressor 2 (see previous screens)
P Compressor status
P Refrigerant pressures
P Refrigerant temperatures
P Load request
P Suction Temp : Suction Temperature
P Suct Superheat : Suction Superheat
P Deliv Superheat : Discharge Superheat
P Valve Position : Position of the electronic expansion valve
0 : Fully closed
2600 : Fully open (Alco EXV8)
Suction Temp = 00.0 ˚C
Suct Superheat = 00.0 ˚C
Deliv Superheat = 00.0 ˚C
Valve Position = 0000
P Staging Up : PID requests a load up of this circuit
P Staging Down : PID requests a load down of this circuit
P Staging Fixed : No actions are needed
P Compressor Off : Compressor is switched off
Staging Up
Staging Down
Staging Fixed
Compressor Off
