Installation and operation manual
21
EUWAC5~10FBZW1
Packaged air-cooled water chillers
4PW61657-1 – 07.2010
ANNEX I
Saturated temperature
The figures below represent the average saturated temperature of
R407C in relation to the pressure readout.
High pressure side
Low pressure side
ANNEX II
Calculation of external pressure drop
10 2015 30255
5
10
15
20
25
30
35
4035 5045 6055 70 °C
bar
65
5
10
9
8
7
6
4
3
2
1
bar
–10 0–5 105–15 2015 3025 4035 50 °C45
5 Hp 8 Hp 10 Hp
General specifications IN OUT IN OUT IN OUT
Nominal air flow (m
3
/min) 70 70 100 100 125 125
long side W
(mm) 763 341 952 802 1102 938
short side P
(mm) 622 314 814 266 865 291
velocity
(m/s) 2.6 11.5 2.5 9.1 2.5 8.7
Friction loss
Pa
0.1 4.6 0.1 2.4 0.1 2.0
Bent parts
R/W=1
Pa
2202152 8
R/W=0.5
Pa
10 70 10 55 10 35
Filter
A Initial resistance
B Recommended final resistance
v Velocity
Louver
A Condenser air flow
v
eff
Effective velocity
1m
90
80
7
0
60
5
0
4
0
30
2
0
1
0
0
2
0
1
v>2m/s
v<2m/s
v<2m/s
A
A
B
v
(
m/s
)
∆
P
(
Pa
)
5
0
4
0
30
2
0
1
0
0
A
2
0
1
5
3
4
∆
P
(
Pa
)
v (m/s)
v
v
v
eff
