Daikin ER60MZY [6/14] Specifications

ELECTRICAL SPECIFICATIONS

UNITS ER*40MZY ER*50MZY ER*60MZY

POWER SUPPLY Y1

NOMINAL DISTRIBUTION SYSTEM

VOLTAGE

Phase 3

Frequency Hz 50

Voltage V 400

Voltage tolerance % ± 10%

UNIT Starting current A 158 193 248

Nominal running current

cooling

A 70 84 104

Maximum running current A 95 120 135

Recommended fuses according to IEC

standard 269-2

aM 3 x 125gL 3 x 160gL 3 x 160gL

FANS Nominal running current A 4 x 1.9 4 x 3.1

Maximum running current A 4 x 1.9 4 x 3.1

Starting current - DOL A 9.5 A per fan-6sec

COMPRESSOR Phase 3

Voltage V 400 ± 10%

Starting current A 158 193 248

Nominal running current A 62 70 90

Maximum running current A 87 106 121

Starting method Star-delta

Recommended fuses −

CONTROL CIRCUIT Phase 1 phase

Voltage V 230V/24V AC (supplied by factory installed transformers)

Recommanded fuses Factory installed

Crankcase heater (E1/2 HC) 1 x (150W - 0.65A)

Liquid line solenoid valves

(Y15..16S/Y25..26S)

2 x (16.1VA - 70mA) inrush current = 130mA

Capacity solenoid valves

(Y11..14S/Y21..Y24S)

3 x (16.1VA - 70mA) inrush current = 130mA

3TW54371-2A

NOTES

1 Cooling capacity / Power input conditions: Ambient 35°C; Suction dewpoint = 5°C; Superheat = 10°C

•

Remote evaporator • R-407C • ER40-60MZY

Specifications

• Condensing Units
