Follow these steps for continuity testing:

1. Connect the black test lead to the COM input.

2. Connect the red test lead to the VΩHz%ns input.

3. Connect the two leads together to verify that the

continuity function is working properly. The

instrument should have a continuous beep sound.

4. Probe with the test leads to the DUT and take the

measured reading on display.

5. If continuity is good, it will have a continuous beep

sound.

Figure 4 - Connection for Continuity Test

WARNING:

Do not apply more than 1000 V DC across the

terminals or they will be damaged.

2.7 Make Capacitance Measurements

Turn the rotary switch to the corresponding symbol for the

measurement you would like to perform.

WARNING:

Fully discharge the capacitor before connecting it

to any of the inputs or it may damage the

instrument.

20 A

uAmA

COM

V.Ω

Continuity
