![B&K PRECISION BK393 [26/31] Duty cycle](/views2/1664593/page26/bg1a.png)
26
Capacitance (6000 counts)
Range
Resolution
Accuracy
6 nF
0.001 nF
+(3.0% rdg + 30 dgt)
60 nF
0.01 nF
+(3.0% rdg + 10 dgt)
600 nF
0.1 nF
+(3.0% rdg + 10 dgt)
6 μF
0.001 μF
+(3.0% rdg + 10 dgt)
60 μF
0.01 μF
+(3.0% rdg + 10 dgt)
600 μF
0.1 μF
+(3.0% rdg + 10 dgt)
6 mF
1 μF
+(5.0% rdg + 10 dgt)
Overload protection: 600 V DC or 600 V AC RMS
Temperature
Range
Resolution
Accuracy
Sensor Type
-50°C - 0°C
0.1° C
+(2.0% rdg + 3°C)
K-type
Thermocouple
0°C -
400°C
0.1° C
+(1.0% rdg + 1°C)
400°C -
1300°C
0.1° C
+(2.0% rdg + 3°C)
-58°F -
32°F
0.1° F
+(2.0% rdg + 6°F)
32°F -
750°F
0.1° F
+(1.0% rdg + 2°F)
750°F -
2372°F
0.1° F
+(2.0% rdg + 6°F)
Overload protection: 30 V DC or 30 V AC RMS
% Duty Cycle
Range
Resolution
Accuracy (5V logic)
Pulse
Width
5% to 95%
0.1%
+(2.0% rdg + 10 dgt)
>10 μs
Frequency range:
5% to 95% (40 Hz to 1 kHz)
10% to 90% (1 kHz to 10 kHz)
20% to 80% (10 kHz to 20 kHz)
Overload protection: 600 V DC or 600 V AC RMS
