GW INSTEK GDM-350B [11/34] Measurement operation
![GW INSTEK GDM-350B [11/34] Measurement operation](/views2/1664893/page11/bgb.png)
MEASUREMENT OPERATION
9
MEASUREMENT OPERATION
First check to see that the 9V battery is charged. Turn the rotary switch to a
measurement position. If the battery charge is low, the “ ” indicator will be
displayed on LCD panel. Ensure the input voltage or current does not exceed
250Vrms and 10A, respectively.
