OVERVIEW

Overall Specification

1. Maximum voltage between any terminal and ground: Refer to the different

input protection voltage ranges shown on the terminals.

2. 10A terminal: Set (CE) 10A H 240V Fast Type Ceramic Fuse φ6x25mm.

3. mA terminal: Set (CE) 1 A H 240V Fast Type Ceramic Fuse φ6x25mm.

4. Operating temperature: 0˚C~40˚C, 32˚F ~104˚F.

Relative Humidity: 0˚C ~30˚C below ≤75%, 30˚C ~40˚C below ≤50%.

Storing temperature:-10˚C ~50˚C (14˚F ~122˚F).

5. Electromagnetism:

Under 1V/m emission: Best Total Accuracy= Specific Accuracy +

Measurement 5%, Over 1V/m emission does not have any specific index.

6. Elevation: 0~2000m.

7. Internal battery: 9V 6F22 or NEDA 1604 or 006P.

8. Low Battery: indicated by “ ” on the LCD display.

9. Product size: 72mm×137mm×35mm.

10. Net Weight: About 200g (battery included).

11. Safety Standard:

IEC/EN 61010-1: CATIII 250V, Pollution Degree 2.

12. Conformance: CE.
