GW INSTEK GDM-350B [31/34] Diode transistor
![GW INSTEK GDM-350B [31/34] Diode transistor](/views2/1664893/page31/bg1f.png)
ACCURACY SPECIFICATIONS
29
Diode, Transistor
Function
Range
Resolution
Remark
Diode
1mV
Display positive voltage decline
Transistor
hFE
1
Continuity Test
Function
Range
Resolution
Remark
Continuity Test
1Ω
<10Ω Buzzer beeps continuously
Overload Protection: 250V DC or AC.
