METRIX MTX3290 [12/63] Description of the instruments continued

Description of the instruments

12 6,000- and 60,000-count digital multimeters

Description of the instruments (continued)

This symbol indicates the battery charge level.

Volt, Ohm, temperature, etc. measurement input

COM measurement input

Ampere measurement input

600V CAT III

Input indication

1000V CAT III

Input indication

Isolated optical link (USB) input

Display of unit on the main display unit (2x14 segments)

Display of unit on the secondary display unit (2x14 segments)

Identifies the reminder of the display zone connection

() When voltages exceeding 60 VDC or 25 VAC are measured, the symbol flashes on the display unit.
