General directions
6,000- and 60,000-count digital multimeters 3
General directions
Introduction
Congratulations! You have just acquired a portable multimeter with a
display digital.
We thank you for this sign of confidence in the quality of our products.
The line of instruments to which it belongs comprises the following models:
MTX 3290
MTX 3291
Display
digital, monochrome,
(70x52)
digital, monochrome,
backlit (70x52)
Power supply
4 R6 primary batteries (AA format) or 4 rechargeable batteries
Counts
6000
60000
Communication
-
IR/USB
It complies with safety standard NF EN 61010-1 + NF EN 61010-2-030
concerning electronic measuring instruments.
For best results, read this manual closely and observe the precautions of use.
Failure to observe these warnings and/or directions may damage the instrument
and/or its components and may endanger the user.
Precautions and
safety measures
This instrument is been designed to be used as follows:
- indoors
- in an environment of pollution degree 2
- at an altitude of less than 2000m
- at a temperature between -10°C and 55°C
- at a relative humidity below 80% up to 31°C.
The safety of any system incorporating the instrument is the responsibility
of the system integrator.
Can be used for measurements on circuits:
- MTX 3290: 600V, CAT III and 300V, CAT IV.
- MTX 3291: 1000V CAT III and 600 CAT IV.
However, some accessories may lead to the use of this instrument on
circuits of a lower voltage and category.
before use
Comply with the environmental and storage conditions.
Check the integrity of the guards and insulation of the accessories. Any item
of which the insulation is deteriorated (even partially) must be removed from
service and scrapped. A change of colour of the insulation is a sign of
deterioration.
during use
Read closely all notes preceded by the symbol.
As a safety measure, use only the appropriate leads and accessories
supplied with the instrument or approved by the manufacturer.
