AXIOMET AX-6003P [4/10] Step key input

The data can have only one decimal point. If one data input

has more than one decimal point, only the first one is valid.

After input a new value, press key [Enter] to validate it. If

the input data has error, there are three ways to correct it.

Method 1: If the destination side of output signal can receive

the wrong signal, press key [Enter] to terminate the current

operation. Input the correct data, and press the key [Enter]

to validate the input.

Method 2: If the destination side of output signal can not

receive the wrong signal, the wrong input is not validated

because of no any wrong signal at the output. Reselect the

operation, input correct data, and press the key [Enter] to

validate the input.

Method 3: Press keys [Shift] [Enter], then input the correct

data, and press the key [Enter] to validate the input.

6. Step Key Input

In practices, a set of voltage or current value with same inter-

val is commonly used. It is complicated and time consuming

to input this kind of data by repeatedly pressing the numeric

keypad and Enter key. It is also complex by using the rotary

knob because voltage or current value may be multi-digit.

It is very convenient to use the step input method. Every

pressing the corresponding soft key can make the voltage or

current increase or decrease by a step value. The modified

data is validated automatically without pressing the Enter

key.

For example, to generate a series of voltage with interval

1.1V, press the keys sequentially as following:

Press keys [Shift] [Menu] to enter function setting interface,

Press key [Menu] again until “Utility V Step” is shown on

the LCD,

Press keys [1] [.] [1] [Enter] to complete step voltage value

setup,

Press key [V-Set/I-Set] again until “Voltage” is shown on

the LCD,

Press keys [Shift] [<] to increase the voltage by 1.1V or

press keys [Shift] [>] to decrease the voltage by 1.1V. Re-

peat this operation, a series of voltage with equal interval

can be generated. The same procedure can be used for the

current operation.

7. Knob Adjustment

In some applications, it requires to adjust the output signal

continuously. Using the rotary knob can complete this task.

Press key [<] or [>] to move the cursor left or right. Rotate

the knob to the right to continuously increase the cursor-lo-

cated digit by 1 and make the carry to a higher unit position.

Rotate the knob to the left to continuously decrease the cur-

sor-located digit by 1 and make the carry to a lower unit

position. When you use the knob to modify a specified data,

the modified data is validated instantaneously without press-

ing the Enter key. A coarse adjustment is made by moving

the cursor to the left; and a fine adjustment is made by mov-

ing the cursor to the right.

8. Parameters Setup

8.1. Output Voltage Setting

Press key [V-Set/I-Set] until “Voltage” is shown on the LCD.

Setting method 1: Press [Number key (voltage value)] [En-

ter] to set output voltage.

Setting method 2: Press [Number knob (voltage value)] to

change the output voltage setting immediately. When use

this method with the output ON, the output voltage will

be changed following the input value by rotating the knob.

Press key[<] or [>] to move the cursor left or right, and tune

the rotary knob left or right to add or subtract the digit on

cursor, or to decrease or increase the digits continuously by

steps, so as to make coarse or fine adjustment of the voltage.

Apply the same procedures for other parameters adjustments.

For example: Set output voltage to 32.000V.

Press [V-Set] [3] [2] [.] [0] [0] [0] [Enter].
