[Enter] to set start memory address.
Setting method 2: Press [Number knob (memory address)]
to change start memory address immediately.
For example: Set the start memory address to 0.
Press [0] [Enter].
8.18. End Memory Address Setting
Press key [Menu] until “Auto End” is shown on the LCD.
Setting method 1: Press [Number key (memory address)]
[Enter] to set end memory address.
Setting method 2: Press [Number knob (memory address)]
to change end memory address immediately.
For example: Set the end memory address to 8.
Press [8] [Enter].
8.19. Cycle Times Setting
Press key [Menu] until “Auto Cycle” is shown on the LCD.
Setting method 1: Press [Number key (cycle times)] [Enter]
to set cycle times from number 0 to 99999. Number 0 repre-
sents infinite loop.
Setting method 2: Press [Number knob (cycle times)] to
change cycle times immediately.
For example: Set the cycle times to 99.
Press [9] [9] [Enter].
8.20. Enter/Exit Auto Running Operation
Press [Auto] to enter or exit the auto running operation mode.
If the Auto key light turns on, it means the instrument has
entered the auto running operation.
Under this mode, LeftTime shown on the LCD represents
the left time, LeftCycle represents left executed cycles, No.
means the memory address, High/Low is high or low range.
(The message High/Low is only for the models with dual
range.)
8.21. Output
The Output key is for turning on or off the output.
8.22. Lock
The Lock key is for locking up the panel setting. When the
key light turns on, the other key and knob is disabled except
Lock and Output key.
8.23. CV/CC Switch
When the output current level reaches the setting with the
Output ON, the CC indicator turns red, the instrument op-
erates in Constant Current mode. When the output voltage
level reaches the setting, the CV indicator turns green, the in-
strument operates in Constant Voltage mode. The instrument
automatically switches between Constant Current mode and
Constant Voltage mode, according to load condition.
8.24. Over Temperature Protection
The instrument provides the Over Temperature Protection
function. In order to insure user’s safety and safe opera-
tion for instrument, the output will automatically turns off if
the instrument produces abnormal high temperature during
operation process.
8.25. Operation methods
8.25.1.
The applied Voltage/Current Unit for this series instruments
is Volt and Amp.
8.25.2. Constant Voltage Operation
Connect load to output terminal.
For the safety, when connect the load to output terminals of
(+) and (-), it must turn off the power.
Select output range.
Turn on the power after the load is well connected, select the
adequate operation range by pressing [High] or [Low].
Set the current limit value.
Press [V-Set/I-Set] until “Current” is shown on the LCD, the
panel operation is set to current value input mode, set the
desired change value by using the number key or the knob
