Daikin EUWA080BZ6Y [11/47] 1 technical specifications
![Daikin EUWA080BZ6Y [11/47] 1 technical specifications](/views2/1665063/page11/bgb.png)
1
3
• Applied Systems • Chillers
11
• Chillers • R-407C • EUWA-BZ6Y
Fan Type Propeller
Drive Direct drive
Nominal air flow m
3
/min 878 923 1438 1383 1322
Model Quantity 6 6 6 6 6
Speed rpm 680 680 680 680 680
Motor
Output
W 600 600 1400 1400 1400
Discharge direction Vertical
Compressor Type Hermetically sealed scroll compressor
Refrigerant oil type 0057E (3.75l) or 00.58E (18.75l)
Refrigerant oil charge l 13.2 14.2 17.0 19.8 11.8
l 13.2 14.2 17.0 19.8 11.8
Model Quantity 4 4 4 6 4
Model 15T 10T 15T 15T 25T
Speed rpm 2900 2900 2900 2900 2900
Crankcase
Heater
W 160 160 160 160 150
Model Quantity
-
22
--
Model 15T 10T
Speed rpm 2900 2900
Crankcase
Heater
W 160 160
Sound Level Sound Power dBA 89 89 94 95 95
Refrigerant circuit Refrigerant type R-407C
Refrigerant charge kg 22.0 27.0 27.0 34.0 31.0
kg 22.0 27.0 27.0 34.0 31.0
No of circuits 11111
Refrigerant control Thermostatic expansion valve
Piping
connections
Evaporator water inlet/outlet ISOR7 - 2 1/2" ISO R7 - 3" ISO R7 - 3" ISO R7 - 3" ISO R7 - 3"
3-2 ELECTRICAL SPECIFICATIONS
EUWA030BZ6Y EUWA035BZ6Y EUWA040BZ6Y EUWA045BZ6Y EUWA049BZ6Y EUWA050BZ6Y
Power Supply Name Y1
Phase 333333
Frequency Hz505050505050
Voltage V 400 400 400 400 400 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Starting Current A 203 215 236 327 336 259
Nominal Running Current
Cooling
A 57.00 69.00 89.00 102.00 111.00 113.00
Compressor Power factor 0.85 0.85 0.85 0.87 0.87 0.85
3-1 TECHNICAL SPECIFICATIONS
EUWA060BZ6Y EUWA070BZ6Y EUWA080BZ6Y EUWA090BZ6Y EUWA095BZ6Y
