Daikin EUWA080BZ6Y [9/47] Specifications
![Daikin EUWA080BZ6Y [9/47] Specifications](/views2/1665063/page9/bg9.png)
1
3
• Applied Systems • Chillers
9
• Chillers • R-407C • EUWA-BZ6Y
3 Specifications
3-1 TECHNICAL SPECIFICATIONS
EUWA030BZ6Y EUWA035BZ6Y EUWA040BZ6Y EUWA045BZ6Y EUWA049BZ6Y EUWA050BZ6Y
Nominal Capacity Cooling kW 62.20 75.50 102.00 120.80 131.30 128.10
Nominal Input Cooling kW 24.70 29.20 39.50 44.60 52.50 49.90
EER & COP EER 2.52 2.59 2.58 2.71 2.51 2.57
Casing Colour RAL9002
Material Powder painted galvanised steel plate
Dimensions Unit Height mm 1790 1790 2048 2048 2048 1790
Width mm 2800 3200 3200 3200 3200 3400
Depth mm 1100 1100 1100 1100 1100 2300
Weight Operating weight without
hydraulic module
kg 842 968 1143 1267 1292 1623
Operating Weight with hydraulic
module
kg 945 1076 1251 1375 1400 1733
Air heat
exchanger
Type Coated aluminium fins with black epoxy coating
Rows x fins per foot 3 x 180 3 x 180 3 x 180 4 x 168 4 x 168 3 x 180
Face Area m
2
3.54 4.12 4.71 4.71 4.71 3.54
Water Heat
Exchanger
Type Brased plate
Minimum water volume in the
system
l 360 360 610 640 620 370
Water flow rate Min l/min 28.8 52.2 52.2 52.2 52.2 73.8
Nominal l/min 178.8 217.8 295.2 333 369 368.4
Nominal water
pressure drop
Cooling kPa 32 36 49 47 53 37
Insulation material Climaflex
ModelQuantity 111111
PumpQuantity 111111
Nominal static height (EUWAB/
EUWAP)
kPa 179 172 137 180 170 199
Hydraulic
components
Buffer tank volume l 370 410 410 410 410 570
Buffer tank additional height mm 400 400 400 400 400 400
Buffer tank additional gross
weight
kg 396 437 436 436 436 644
Hydraulic module weight kg 103 108 108 108 108 110
Antifreeze heater W 150 150 150 150 150 150
Expansion vessel l 25 25 25 25 25 35
Water filter inch233222
Safety valve bar444444
Fan Type Propeller
Drive Direct drive
Nominal air flow m
3
/min 318 438 622 618 618 638
ModelQuantity 233334
Speed rpm 680 680 680 680 680 680
Motor
Output
W 600 600 1050 1050 1050 600
Discharge direction Vertical
