12 Hydraulic performance

12 - 1 Water pressure drop

Water pressure drop at nominal waterflow rate (Without Hydraulic module option)

EUWAN 030 035 040 045 049 050 060 070 080 090 095

Min. water flow - 0% Ethylene glycol (l/s) 0.48 0.87 0.87 0.87 0.87 1.23 1.23 2.23 2.23 2.23 2.23

Min. water flow - 30% Ethylene glycol (l/s) 0.86 1.57 1.57 1.57 1.57 2.21 2.21 4.02 4.02 4.02 4.02

Nominal water flow (l/s) 2.98 3.63 4.92 5.57 6.15 6.14 7.49 8.71 10.25 11.55 12.74

DP (kPa) 32 36 49 47 53 37 45 37 44 44 53

Water pressure drop (Without Hydraulic module option)

EUWAN 030 035 040 045 049 050 060 070 080 090 095

_P (kPa) Water flow rate l/s

10 1.59 1.81 2.11 2.52 2.64 2.66 2.88 3.82 4.07 4.47 5.20

20 2.32 2.63 3.06 3.60 3.76 3.86 4.16 5.52 5.88 6.42 7.55

40 3.38 3.83 4.41 5.13 5.35 5.60 6.03 7.98 8.48 9.24 10.97

60 4.22 4.77 5.47 6.32 6.58 6.97 7.48 9.91 10.51 11.43 13.64

80 4.94 5.57 6.38 7.32 7.61 8.13 8.72 11.54 12.23 13.29 15.92

100 5.58 6.29 7.18 8.21 8.53 9.16 9.83 13.00 13.77 14.94 17.95
