![CHAUVIN ARNOUX CA-MA4000D-350 [25/72] Power supply](/views2/1665979/page25/bg19.png)
25
3.3. VARIATIONS IN RANGE OF USE
Quantity of influence Range of influence
Error on the measurement
Typical Maximum
Battery voltage 1.8 to 2 V
< 1 ct ±(2% + 1 ct)
Temperature 0 °C to 50 °C ± 0.25 % / 10 °C ±( 0.5 % / 10 °C + 2 ct)
Relative humidity 10 to 90% RH 0.2% ± (0.3 % + 2 ct)
Frequency response
10 to 20 Hz
20 Hz to 30 Hz
30 Hz to 400 Hz
400 to 1000 Hz
1000 to 3000 Hz
See § 3.4
± (5 % + 1 ct)
± (1 % + 1 ct)
± (0.5 % + 1 ct)
± (6 % + 1 ct)
‑ 3 dB typical
Position of the conductor in
the sensor (f<400 Hz)
Any position on the interior
perimeter of the sensor
± 0.5 % ± (1.5 % ± 1 ct)
Adjacent conductor
carrying alternating current
Conductor touching the ex‑
terior perimeter of the sensor
Away from opening: 55 dB
At opening: 55 dB
Away from opening: ≥ 45 dB
At opening: ≥ 45 dB
Peak factor
1.4 to 3.5
limited to 6000 Apeak
at 16.66 Hz : ± (2 % + 1 ct)
at 50 Hz : ± (0.5 % + 1 ct)
at 440 Hz : ± (30 % + 1 ct)
± (6 % + 1 ct)
± (3 % + 1 ct)
‑
Serial mode rejection ratio
in AC
0 to 400 Adc < 1 ct ≥ 50 dB
Common mode rejection,
50/60 Hz
0 to 600 V
rms < 1 ct ≥ 60 dB
Influence of a 50/60 Hz ex‑
ternal magnetic field
0 to 400 A/m
Housing: 43 dB
Sensor: 50 dB
Housing: ≥ 30 dB
Sensor: ≥ 40 dB
3.5. POWER SUPPLY
The device can be powered:
either by two 1.5 V R03 (AAA) alkaline batteries,
or by two NiMH storage batteries of the same size.
The nominal operating voltage is between 1.8 and 3.2 V.
The battery life in continuous operation is:
70 hours with super‑alkaline batteries,
50 hours with NiMH storage batteries having a capacity
of 1200 mAh.
The low battery condition is reported by the blinking
symbol on the display unit. When it is lit steadily, the batter‑
ies must be replaced (see § 4.2).
3.8. ENVIRONMENTAL CONDITIONS
The instrument must be used in the following conditions:
Temperature in use: 0°C to +50°C
Storage temperature: ‑20°C to +70°C
(without batteries)
Relative humidity in use: 80% RH to 50°C
Relative humidity in storage: 90% RH (up to 45°C)
The sensor can withstand a temperature of 90°C.
