CHAUVIN ARNOUX CA-F403 [11/42] The symbols of the display unit

1.3.1 The symbols of the display unit

Symbol Designation

Alternating current or voltage

Direct current or voltage

∆

REL

Relative value, with respect to a reference

∆

Ref

Reference value

Storage of the values and hold of the display

Max

Maximum RMS value

Min

Minimum RMS value

Volt

Hertz

Ampere

Percentage

Ohm

Milli- prefix

Kilo- prefix

Compensation of the resistance of the leads

Continuity test

Diode test

Permanent display (automatic switching off de-activated)

Spent battery indicator
