CHAUVIN ARNOUX CA-F403 [12/42] Measurement capacity exceeded o l

1.3.2 Measurement capacity exceeded (O.L)

The O.L (Over Load) symbol is displayed when the display capacity is exceeded.

1.4 THE TERMINALS

The terminals are used as follows:

1 2

Figure 5 : the terminals

Item Function

Cold terminal (COM)

Hot terminal (+)
