CHAUVIN ARNOUX CA-F403 [8/42] The switch

1.1 THE SWITCH

The switch has six positions. To access the , , , , , functions,

set the switch to the desired function. Each setting is confirmed by an audible

signal. The functions are described in the table below.

Figure 2 : the switch

Item Function See §

1 OFF mode – Switches the clamp multimeter off 3.3

2 AC, DC voltage measurement (V) 3.5

3 Continuity test

Resistance measurement Ω

Diode test

3.6

3.7

3.8

4 AC, DC current measurement (A) 3.9

5 Temperature measurement (°C/°F) 3.12

6 Adapter function 3.13
